Pipeline lining stands out as a significant advancement in the rehabilitation of wastewater networks. Economical and environmentally friendly, this process avoids heavy and costly replacement works. In France, it is now preferred by many professionals for its efficiency and quick implementation.

Designed to repair leaks, cracks, or wear related to time, lining gives new life to your pipelines. It relies on the use of resins, either epoxy or polyester, reinforced with fiberglass liners. This mixture guarantees a solid and lasting repair. Preliminary steps, such as video inspection and cleaning, are crucial. They ensure not only the success of the lining but also the improvement of the network's performance over time.

Understanding pipeline lining: Definition and importance

What is pipeline lining?

A revolutionary repair technique, pipeline lining involves renovating damaged pipes from the inside. This process uses a flexible liner soaked in resin which, once cured, forms a new robust and waterproof coating inside the pipeline. Suitable for a wide variety of networks, including sanitation, drinking water, or industrial effluents, this method fits all types of materials.

This innovation originated in the 1970s in London for the Thames Water Company, offering a quick repair solution that avoids trenches and extensive civil engineering works. It has since diversified to include several techniques such as spray lining, continuous or partial lining, adapted according to the situations.

The process begins with precise cleaning and video inspection, ensuring the pipeline is ready for the application of the new coating. The resin, once applied and cured, bonds firmly to the walls, restoring the pipeline's structure.

Why choose pipeline lining?

Pipeline lining is an advantageous option for several reasons. Firstly, it presents itself as a cost-effective alternative to conventional replacements, avoiding the inconveniences of excavation and minimizing disruptions to the environment and users.

The implementation of this method is quick, often completed in one day, limiting the impact on daily life. Less intrusive, it can be carried out from common areas without requiring access to private properties.

Ideal for conduits that are difficult to access or located in sensitive areas, it is particularly suitable for compact urban environments, old buildings, and essential infrastructures where service continuity is crucial.

The advantages of lining compared to traditional methods

Lining surpasses conventional methods by preserving the network structure without total replacement. It increases the resilience of pipes against chemical attacks and prevents leaks and other deteriorations, thus extending their lifespan.

Moreover, this approach improves hydraulic performance thanks to the smooth surface of the coating, facilitating optimal flow. In terms of durability, it represents a long-term solution, better resisting mechanical and environmental stresses, reducing future maintenance and repair costs.

Adopting a sustainable approach, lining reduces the ecological impact of renovation work, highlighting its commitment to resource preservation.

The equipment and materials necessary for pipe lining

The different types of resins used

The selection of the resin is a key point in the lining process, directly impacting the quality and longevity of the rehabilitation. Common types include epoxy, polyester, and vinylester. Epoxy stands out for its excellent adhesion and remarkable resistance to corrosion and chemicals. This makes it the preferred option for pipes carrying effluents, whether domestic or industrial. Polyester, appreciated for its affordability and ease of application, offers lower resistance compared to epoxy. As for vinylester, it is favored for its robustness in acidic environments and its durability over time.

The preparation of the resin requires accuracy in mixing the components, aiming for a uniform consistency. After its application on the liner, it is inserted into the targeted pipe. The curing of the resin, triggered afterward, creates a new internal membrane that is both solid and waterproof.

It should be noted that the chosen resin must match the characteristics of the pipe and its usage conditions. In the presence of high temperatures or aggressive components, the use of a specific epoxy resin is often required for optimal repair.

Essential equipment for effective lining

Lining requires a range of specialized equipment. This includes spray robots for balanced resin application, inversion devices to efficiently insert the resin-impregnated liner, and curing systems to consolidate the resin.

Spray robots ensure a uniform distribution of resin inside the pipe, essential for coating consistency and quality. On the other hand, inversion devices, operating by air or water pressure, facilitate perfect insertion and adhesion of the liner to the walls. Finally, curing methods such as steam or UV lamps accelerate resin solidification, crucial for the structural stability of the lining.

Liner selection: criteria and available options

The liner, or sleeve, plays an essential role in lining. It is a flexible membrane impregnated with resin, prepared to be inserted into the pipe. The choice of liner is based on various criteria: pipe diameter, nature of effluents, and operating conditions.

These liners are mainly made of polyester textiles or fiberglass, ensuring flexibility and mechanical strength. They can be reinforced with materials such as vinylester or carbon, enhancing their chemical or thermal resistance.

Choosing the appropriate liner is crucial. A suitable liner ensures perfect fusion with the resin, resulting in an effective and lasting repair. This precision minimizes the risks of leaks or rapid deterioration of the lining.

Pipe lining techniques: step by step

Pipe preparation

The key to successful lining lies in meticulous pipe preparation. It starts with thorough cleaning, usually via high-pressure hydro jetting, removing debris and residues. This step ensures an ideal surface for proper resin adhesion.

A camera inspection follows, identifying damaged areas and allowing targeted intervention planning. Corroded or leaking zones are treated, sometimes with localized repairs, to achieve a uniform surface, crucial for coating success. An initial report then specifies the length, diameter, and type of pipes as well as the connections to be treated, ensuring appropriate preparation.

Once prepared, the pipes are ready for lining. This preliminary step is crucial to ensure optimal resin adhesion and repair durability.

Inversion lining and pull-in lining: differences and applications

Lining can be done by inversion or by pulling, two distinct techniques adapting to various scenarios. Inversion, which consists of inserting a flexible resin-coated liner by pressure reversal, is a quick method that avoids excavation. It is preferred for pipes with significant structural damage.

Pulling, on the other hand, passes the liner through the pipes, ideal for spot repairs or difficult access. Each method has its own advantages, chosen according to the pipe configuration and the type of damage encountered.

The wise choice of technique is vital for effective rehabilitation while minimizing disruptions.

Post-lining quality control

A rigorous quality control after intervention ensures the integrity and performance of the repair. This control involves pressure tests and video inspections, verifying the watertightness and proper adhesion of the liner.

Additional statistical analyses confirm the quality and longevity of the lining, in accordance with established safety and performance standards.

Regular monitoring is recommended to maintain the condition of the pipes and anticipate potential problems, thus ensuring a lasting solution.

Conclusion

Pipe lining represents a significant advancement, offering an option that is both durable and more affordable than conventional approaches. Using specialized tools and state-of-the-art materials, this technique promises a quick and effective restoration of wastewater pipes.

By choosing this method, you favor an eco-friendly approach. It significantly reduces daily disruptions and preserves our environment. No more hesitation, entrust the evaluation and rehabilitation of your pipes to lining professionals. This way, you ensure the longevity and proper functioning of your installations.

FAQ

How to clean pipes?

Pipe cleaning is mainly done by two methods: using augers for mechanical cleaning, or employing high-pressure technology. These techniques are effective in clearing all blockages.

How to repair drainage pipe under house?

Repairing a drainage pipe located under a house can be done without digging. The lining method is often preferred. It involves inserting a flexible tube impregnated with resin into the damaged pipe, thus creating a new conduit that is both watertight and durable.

How to unclog a cast iron pipe?

A mixture of baking soda, salt, and white vinegar can be effective for unclogging a cast iron pipe. After pouring the solution into the pipe, it is recommended to let it sit for several hours.

Who renovates the pipelines?
