What are the different pipe lining techniques? How to train in pipe lining as a professional?

Pipe lining offers an innovative solution for renovating sanitation networks without requiring the replacement of existing pipes. This method provides significant advantages, notably in terms of cost, minimizing disruption, and environmental protection.

But what exactly does pipe lining involve? What are the different usable processes?

How can one train for this developing profession?

This guide will provide you with a comprehensive overview of pipe lining, covering its principles, uses, and available training paths. You will explore how this revolutionary technique can be applied to wastewater, rainwater, or drinking water pipes, using various materials such as epoxy resin or spray lining.

You will also discover the paths to becoming a pipe lining specialist, through suitable training and obtaining recognized certifications.

Understanding pipe lining: definition and necessity

Let's explore the concept of pipe lining before diving into the different available techniques. This rehabilitation method is crucial to maintaining the integrity of sanitation networks.

Pipe lining is an innovative process aimed at inserting a new coating inside deteriorated pipes. This new layer, often made of fiberglass or felt impregnated with epoxy or polyester resin, adheres to the internal walls to repair damages such as cracks, leaks, deformations, and corrosion.

This technique adapts to various pipe materials, including cast iron, concrete, PVC, and steel. It is also effective for a wide range of applications, from drinking water distribution to the evacuation of wastewater, stormwater, or industrial effluents.

Lining offers several advantages over conventional repair methods, which generally involve significant excavations. Not only does it minimize costs, execution times, inconveniences, and environmental impacts, but it also significantly extends the lifespan of pipes, up to 50 years. Thus, lining presents itself as a durable, fast, and economical option to modernize sanitation infrastructures without requiring their complete replacement.

The different pipe lining techniques

After exploring what pipe lining is and its importance, let's explore the various methods available for this crucial renovation operation. The techniques vary depending on the type of coating used, their application method, and the expected results.

Cold lining or CIPP (Cured-in-Place Pipe)

Cold lining, also known as CIPP, is the most popular method. This technique involves inserting a flexible liner, made of fiberglass or felt, impregnated with epoxy or polyester resin, inside the pipe.

This liner is inflated using pressurized air or water so that it conforms to the internal walls of the pipe. The resin then solidifies, either at room temperature or with a heat source, forming a new watertight and solid conduit.

This method is applicable to pipes of various diameters and shapes (circular, oval, rectangular) and can extend up to 300 meters in length. However, it requires opening the connections after the resin has cured, using a milling robot.

Spray lining (SIPP – Spray-in-Place Pipe)

Spray lining, or SIPP, represents an innovative approach, consisting of spraying resin inside the pipeline using a robot. The resin then creates a continuous layer directly on the walls, without requiring a prior liner.

This technique is ideal for small diameter pipelines (from 50 to 300 mm), of all shapes, and can cover up to 100 meters in length. One of its major advantages is eliminating the need for milling connections, as the resin naturally takes the shape of the joints. It also allows adjusting the coating thickness according to the pipeline's condition.

Alternative lining techniques

Other less traditional methods exist to meet specific needs. For example, spot lining, which focuses on repairing a determined section of pipeline without working on its entirety.

There is also lining with a four-layer coating, a more complex process that starts with internal brushing of the pipeline followed by the application of special compounds for enhanced protection against corrosion and pressure loss. These alternatives tend to be more expensive and less effective than cold lining or spray lining.

Becoming a professional in pipeline lining

Understanding the basics of pipeline lining is one thing, but aspiring to become an expert in this growing field is another. What must be done to develop the skills and knowledge necessary to carry out quality work safely? Which training should be chosen and why is regular practice crucial? We offer answers to these questions as well as advice for effective pipeline lining training.

Dedicated training: content and objectives

Training specially designed for pipeline lining professionals covers essential elements, including:

• Selection and handling of resins and lining materials.
• Correct use and maintenance of lining equipment.
• Lining methods adapted to different types of pipelines.
• Reading plans and adhering to technical specifications.
• Compliance with safety standards and accident prevention.
• Environmentally friendly practices and effective waste management.

These programs aim to equip you with the essential skills to properly handle materials, master equipment, identify the best processes according to situations, comply with current standards, and ensure the quality and safety of interventions.

Choosing the right training

To find the training that suits you, evaluate it according to several criteria:

• The content and objectives of the training must meet your needs and aspirations.
• Duration and cost must align with your budget and availability.
• Approval and certification by official bodies guarantee the value of the training.
• The experience and expertise of trainers are paramount for quality learning.
• Teaching methods should promote a balance between theory and practice.

Comparing different trainings, asking additional questions, and gathering information before committing is highly recommended.

Practice: an essential component of learning

It is crucial to emphasize the importance of practice in mastering pipe lining. To excel in this profession, theoretical knowledge must be complemented by regular field training supervised by experienced professionals. Practice allows to:

• Strengthen theoretical knowledge.
• Refine technical and manual skills.
• Increase self-confidence and autonomy.
• Prepare for real challenges and unforeseen events.
• Stay at the forefront of technological developments and new methods.

Practice is thus a pillar of professional training in pipe lining, essential to meet customer expectations.

Conclusion

This article introduced you to pipe lining, a revolutionary method for rehabilitating sanitation networks. This technique allows inserting a new lining inside damaged pipes, thus avoiding their complete replacement. You explored the basics, benefits, different approaches to lining, as well as training options and criteria to embrace this booming career. Emphasis was also placed on the importance of practice to acquire the skills and knowledge essential for performing safe and quality work.
